1500 Membrane (16bar) (shifter)
浏览次数:
  • 1500 Membrane (16bar) (shifter)

技术规格 资料下载





XG1500 Membrane (shifter) (16bar)
Filter pressure≤1.2MpaDiaphragm plate size1500*1500*85Cylinder diameterD320mm*2
Membrane squeezing pressure≤1.6MpaFilter chamber depth before the squeeze40mmMaximum stroke of oil cylinder800mm
Cylinder pressure when plates
 closing
≤20MpaMain oil pump motor power7.5kw

Chamber plate size1500*1500*78Plate shifter motor power1.1kw



ModelFilter area(㎡)Number of diaphragm plates (pieces)Number of chamber plates (pieces)Number of filter chambers (pieces)Foot center distance L1(mm)Overall size L*W*H(mm)Filter chamber volume before squeezing (L)Total weight(kg)
XG150FYZ16Z3-200U20026255262107792*2281*1815400020600
XG150FYZ16Z3-220U22028275665408122*2281*1815440021200
XG150FYZ16Z3-240U24031306270358617*2281*1815480022000
XG150FYZ16Z3-280U28036357278609442*2281*1815560023500
XG150FYZ16Z3-300U30039387883559937*2281*1815600024400
XG150FYZ16Z3-320U320414082868510267*2281*1815640024900
XG150FYZ16Z3-340U340444388918010762*2281*1815680025800
XG150FYZ16Z3-350U350454490934510927*2281*1815700026100
XG150FYZ16Z3-400U40051501021033511917*2281*1815800027800
XG150FYZ16Z3-450U45058571161149013072*2281*1815900029900
XG150FYZ16Z3-500U50064631281248014062*2281*18151000031600
