1500 Membrane

HOME > PRODUCTS > Filter presses > Membrane filter press > 1500 Membrane

1500 Membrane (16bar) (bomb bay doors)
浏览次数：
  • 1500 Membrane (16bar) (bomb bay doors)

技术规格 资料下载





XG1500 Membrane (bomb bay doors) (16bar)
Filter pressure≤1.2MpaDiaphragm plate size1500*1500*85Motor power of bombay doors oil pump1.5kw
Membrane squeezing pressure≤1.6MpaFilter chamber depth before the squeeze40mmCylinder diameterD320mm*2
Cylinder pressure when plates closing≤20MpaMain oil pump motor power7.5kwMaximum stroke of oil cylinder800mm
Chamber plate size1500*1500*78Plate shifter motor power1.1kw



ModelFilter area（㎡）Number of diaphragm plates (pieces)Number of chamber plates (pieces)Number of filter chambers (pieces)Foot center distance L1(mm)Overall size L*W*H（mm）Filter chamber volume before squeezing (L)Total weight（kg）
XG150FYZ16Z3F1-200U20026255262107792*2281*2164400022200
XG150FYZ16Z3F1-220U22028275665408122*2281*2164440022800
XG150FYZ16Z3F1-240U24031306270358617*2281*2164480023600
XG150FYZ16Z3F1-280U28036357278609442*2281*2164560025100
XG150FYZ16Z3F1-300U30039387883559937*2281*2164600026000
XG150FYZ16Z3F1-320U320414082868510267*2281*2164640026500
XG150FYZ16Z3F1-340U340444388918010762*2281*2164680027400
XG150FYZ16Z3F1-350U350454490934510927*2281*2164700027700
XG150FYZ16Z3F1-400U40051501021033511917*2281*2164800029400
XG150FYZ16Z3F1-450U45058571161149013072*2281*2164900031500
XG150FYZ16Z3F1-500U50064631281248014062*2281*21641000033200
