1500 Membrane (16bar) (cloth washer)
浏览次数：
  • 1500 Membrane (16bar) (cloth washer)

技术规格 资料下载





XG1500 Membrane (cloth washer) (16bar)
Filter pressure≤1.2MpaFilter chamber depth before the squeeze40mmCloth washing rack moving motor power0.55kw*2
Membrane squeezing pressure≤1.6MpaMain oil pump motor power7.5kwCylinder diameterD320mm*2
Cylinder pressure when plates
 closing		≤20MpaPlate shifter motor power1.5kwMaximum stroke of oil cylinder800mm
Chamber plate size1500*1500*78Motor power of bombay doors oil pump1.1kw

Diaphragm plate size1500*1500*85Cloth washing rack up and down motor power1.1kw



ModelFilter area（㎡）Number of diaphragm plates (pieces)Number of chamber plates (pieces)Number of filter chambers (pieces)Foot center distance L1(mm)Overall size L*W*H（mm）Filter chamber volume before squeezing (L)Total weight（kg）
XG150FYZ16Z3F1Q1-200U20026255263087890*3087*4754400023600
XG150FYZ16Z3F1Q1-220U22028275666388220*3087*4754440024200
XG150FYZ16Z3F1Q1-240U24031306271338715*3087*4754480025000
XG150FYZ16Z3F1Q1-280U28036357279589540*3087*4754560026500
XG150FYZ16Z3F1Q1-300U300393878845310035*3087*4754600027400
XG150FYZ16Z3F1Q1-320U320414082878310365*3087*4754640027900
XG150FYZ16Z3F1Q1-340U340444388927810860*3087*4754680028800
XG150FYZ16Z3F1Q1-350U350454490944311025*3087*4754700029100
XG150FYZ16Z3F1Q1-400U40051501021043312015*3087*4754800030800
XG150FYZ16Z3F1Q1-450U45058571161158813170*3087*4754900032900
XG150FYZ16Z3F1Q1-500U50064631281257814160*3087*47541000034600
